GATE 2024 Electrical Engineering (EE) Question Paper: Download Memory-Based Questions

GATE 2024 Electrical Engineering (EE) Question Paper: Today, Feb 11, 2024, the conducting authorities held the GATE exam, for which the GATE 2024 EE question paper is given below. Participants of the GATE exam must check the official website to download the GATE 2024 Electrical Engineering (EE) question paper upon its release. The GATE 2024 Electrical Engineering (EE) Answer Key is also available.

 Also Read: GATE 2024 Electronics and Communication Engineering (EC) Answer Key

GATE 2024 Electrical Engineering (EE) Question Paper

The memory-based questions from the GATE 2024 EE Question Paper are given below:

• Consider the stable closed loop system shown in the figure. The asymptotic bode magnitude plot G(s) has a constant slope of –20 dB/dec at least till 100 rad/sec with the gain crossover frequency being 10 rad/sec. The asymptotic bode phase plot remains constant at –90° at least.  = 10 rad/sec. The steady state error of the closed system for a unit ramp input is ______ . (Rounded off to 2 decimal phase).

• A three phase 50 Hz 6 pole induction motor runs at 960 rpm the stator copper less. Core less and rotate or less of the motor car be neglect the % eco efficiency of motor
  (a) 98
  (b) 94
  (c) 96
  (d) 92

• A single-phase time based, A.C voltage controller feeds RL load. The input a.c supply is 230 volts, 50Hz. The values of R and L are 10 and 18.37 mH respectively. The minimum triggering angle of the triac to obtain controller output voltage is
  (a) 30°
  (b) 60°
  (c) 45°
  (d) 15°

• If the following switching devices have similar power ratings, which one of them is the fastest
  (a) G.T.O
  (b) Power mosfet
  (c) IGBT
  (d) SCR

• A 3-phase 11 kV, 10 mVA synchronous generator is connected to an inductive load of power factor via a loss less line with 3-phase inductive reactance of 5Ω . The per phase synchronous reactance of the generator is 30  with negligible armature resistance. If the generator produces the rated current at the rated voltage. Then the power factor at the terminal of the generator.
  (a) 0.63 lagging
  (b) 0.63 leading
  (c) 0.87 leading
  (d) 0.87 lagging

• A 3-phase star connected slip ring induction motor has the following parameter referred to the stator. RS = 3, XS = 2 , Xr’ = 2, R’r = 2.5. The per phase stator to rotor effective tern ratio 3 : 1, the rotor winding is also star connected the magnetizers reactance and core less of the motor can be neglected to have maximum torque at starting the value of the extra resistance in ohms (referred to rotor side) to be connected in series with each phase of the rotor winding is ________ (2 decimals).
• Suppose signal y(t) is obtained by the time reversal of signal x(t), i.e. y(t) = x (– t) which one of the following options is always taken about when y(t) is convolved with x(t).
  (a) Odd signal
  (b) Causal signal
  (c) Even signal
  (d) Anticasual signal
• Let f(t) be a real valued function whose second derivative is positive for – ∞ < t < ∞. Which of the following statements is always true?
  (a) The minimum value of f(t) cannot be negative
  (b) Has at least one local maximum
  (c) f(t) cannot have two distinct local minimum
  (d) f(t) has at least one local minimum
• In the (X, Y, Z) coordinate system, three point charge Q, Q and Q are located in free space (–1, 0, 0), (1, 0, 0) and (0, –1, 0) respectively. The value of ‘’ for the electric field to be zero at (0, 0.5, 0) is ________ . (Rounded off to 1 decimal places.)
• A 5 kW, 220 V DC shunt motor has 0.5 Ω are armature resistance including brushes. The motor draws a no-load current of 3A. The field current is constant 1 A. Assuming that the core and rotational losses are constant and independent of the load, the current in (A) drawn by the motor while delivering the rated load for the best possible efficiency is _______ .

Candidates can check out the the remaining questions by following the GATE 2024 Electrical Engineering (EE) question paper link given below.

Highest Marks in GATE Electrical Engineering (EE)

Here, participants can check out the highest marks in GATE Electronics and Communication Engineering (EC) for the previous years to draw an estimate for the GATE 2024 Electronics and Communication Engineering (EC) question paper accordingly.

Based on the participant's memory, the GATE 2024 Electrical Engineering (EE) question paper has been accumulated. Further, the GATE 2024 Electrical Engineering question paper provides students a chance to recall their responses. Candidates can expect the official GATE Electrical Engineering question paper 2024 to be issued online soon.

The GATE 2024 Electrical Engineering (EE) question paper helps the candidates analyze their performance. Once the official answer key is out along with the GATE Electrical Engineering (EE) question paper 2024, the participants can draw an estimated calculation of their results until the GATE result 2024 is announced.
