1
|
Give the Block diagram of the Transmission of Electricity from the power station to the consumer.
|
|
2
|
Give the reason for Power Transmission at a very high voltage (132 KV).
|
|
3
|
At the Generating Station, why is the electric power generated at 11 KV?
|
|
4
|
What is the meaning of "The frequency of alternating current is 50 Hz"?
|
|
5
|
What is the meaning of Live, Neutral and Earth wire and use of each wire in the circuit along with their colour coding?
|
|
6
|
Draw the diagram of the Ring System of the House Wiring with basic components and give the advantages of the Ring System.
|
|
7
|
What are the disadvantages of connecting the appliances in Series and the advantages of connecting them in Parallel?
|
|
8
|
What are the uses of Switch, Fuse, MCB, Earthing, 3-pin plug and 3-pin socket?
|
|
9
|
Why Fuse and Switch present in Live Wire?
|
|
10
|
Draw the diagram of Staircase wiring.
|
|
11
|
How Earthing prevents electric shock in the circuit and how it is useless if the Fuse is not present in the Live wire?
|
|
12
|
Draw a diagram of 3-pin plugs and a Socket.
|
|
13
|
State one circumstance, when one may get an electric shock from an electric gadget and one preventive measure to be provided with the gadget to avoid it.
|
|
14
|
Point out main differences between Overloading and Short-Circuiting.
|
|
15
|
Name the material which is used as the fuse wire.
|
|
16
|
Why is earthing of an electrical appliance necessary?
|
|
17
|
State the factors on which the resistance of a wire depends. Also, state how it is affected by the factors stated by you.
|
|
18
|
Why should switches always be connected with the live wire?
|
|
19
|
Explain the meaning of the statement ‘the power of an appliance is 100W’.
|
|
20
|
Define household units of electricity.
|
|
21
|
Why is the earth terminal in a plug made (i) thicker (ii) longer as compared to live or neutral terminals.
|
|
22
|
Define the materials used for making fuse wire. State two properties of material of fuse wire which make it suitable for use.
|
|
23
|
Explain the meaning of the statement ‘current rating of a fuse is 5A’.
|
|
24
|
Two fuse wires are rated 5A and 20A. Which of the two is (i) thicker (ii) longer
|
|
25
|
Draw the diagram of a dual control switch when the appliance is switched ‘ON’.
|
